| Model No. | JBC200F9N-E4IN-B |
| Part No. | HBJC200F9N-E4IN-B |
| Motherboard Specification |
| CPU | Intel® Celeron N2930 SoC, 1.83GHz – 2.16GHz Burst, Quad-Core, 7.5W TDP/4.5W SDP |
| Memory | 2 x 204-pin SODIMM DDR3L-1333 Single Channel up to 8 GB (1.35V required) |
| VGA | Intel HD Graphics, 313MHz - 854MHz |
| LAN | 1 x Intel i211AT Gigabit Ethernet 4 x Intel 82574L Gigabit Ethernet (Jetway ADE4INLANG GEN2 Daughter Board)
 |
| Audio | Realtek ALC662 5.1 Channel HD Audio with 3W Amplifier |
| Storage | 2 x SATA2 3Gb/s Connectors 1 x Full-size mSATA slot
 |
| Mini-PCIE Slot | 1 x PCI Express Mini Card Slot (Full-size) |
| USB | Embedded 1 x USB 3.0 & 5 x USB 2.0 |
| Form Factor | Mini-ITX Form Factor, 170 x 170mm |
| Chassis Specification |
| Product size | 210(W) x 258(D) x 65(H)mm |
| Color | Black |
| Chassis Bays | 1 x Slim Optical Drive Bay 1 x 2.5" Hard Disk Drive Bay
 Additional 2.5” drive can be installed if optical drive and mSATA are not installed
 |
| System Fan | Side: 6cm Fan SLEEVE x 1 |
| Front I/O Port | 1 x Power Button 2 x USB 2.0
 |
| Rear I/O Port | 1 x PS2 Keyboard 1 x PS2 Mouse
 1 x VGA
 1 x RS232 COM Port
 3 x USB 2.0
 5 x RJ45 LAN (10/100/1000)
 1 x +12 DC-in jack
 1 x HDMI
 1 x USB 3.0
 1 x 3.5mm Audio Jacks (Line Out)
 |
| Power Source | 12V DC Power-On-Board |
| Expansion Slots | 1 x Full-size mini PCI Express x1 Slot (open) |
| Standard Accessory | √ 60W AC-DC Adapter x1 √ Power Cord x1
 √ Vertical Stand x4
 √ CD Disk x1
 √ Manual x1
 √ Screw Pack x1
 √ HDD SATA Cable x1
 |
| Certificate | CE,FCC,ErP For Barebone CE,FCC,TUV,UL,CCC,CB,ErP For Power Adapter
 |
